ASUS TUF GAMING A620AM-PLUS WIFI takes all the essential elements of the latest AMD Ryzen™ processors and combines them with game-ready features and proven durability.
Engineered with military-grade components, an upgraded power solution and a comprehensive cooling system, this motherboard goes beyond expectations with rock-solid and stable performance for marathon gaming. TUF GAMING motherboards also undergo rigorous endurance testing to ensure that they can handle conditions where others may fail. This platform delivers the power and connectivity that advanced AI PC applications demand.
- AMD A620A mATX motherboard
- Advanced AI PC ready
- DDR5
- PCIe 4.0 x16 slot
- Dual PCIe 4.0 M.2 slots
- Wi-Fi 6
- Realtek 2.5Gb Ethernet
- Dual DisplayPort,
- HDMI
- Rear USB 10Gbps Type-A ports
- Front USB 5Gbps Type-C connector
- BIOS FlashBack
- M.2 Q-Latch
- Aura Sync
Intelligent Control
- AI Cache Boost - Supercharge your large language model (LLM) workflows with AI Cache Boost. Exclusive to ASUS AMD 800 and 600 series motherboards that use Ryzen™ 9000 Series CPUs, this BIOS setting optimizes CPU cache and memory pathways to deliver up to 29% faster local LLM performance with high-speed memory tuning.
- UEFI BIOS - The UEFI interface delivers easy-to-use configuration options for PC beginners, and advanced features for veterans.
- ASUS DriverHub - Simplify driver management with automatic detection, one-click installation and update for smooth, efficient system performance.
- Armoury Crate - Customize Aura Sync RGB and control ASUS devices. Includes product registration and updates.
Digital Power Design
TUF GAMING A620AM-PLUS series motherboards feature an 8+2+1 phase power design with discrete MOSFETs, ensuring efficient and stable power delivery for AMD processors plus steady performance for day-to-day use.
Memory & Storage
Cooler by Design
- Enhanced VRM Heatsink - The extensive surface area of this heatsink covers the MOSFETs and chokes to improve thermal performance.
- Multiple Temperature Sources - Each header can dynamically reference three thermal sensors. Fan Xpert 2+ allows you to map the temperature of supported ASUS graphics cards to optimize cooling for GPU- and CPU-intensive tasks.
- Smart Fan Protection - A dedicated integrated circuit protects each fan header from excess heat and electrical currents.
- Superb PCH Heatsink - A surface area for the chipset cooler maximizes system performance and heat dissipation.
- 4-Pin PWM/DC Fan - All onboard fan headers support auto-detection of PWM or DC fans.
- Cooler Compatibility - ASUS AIO coolers offer robust performance, high overclocking potential, bold aesthetics and customizable functionality for new TUF Gaming motherboards, empowering you to build your dream gaming rig.
Connectivity
-
PCIe 4.0 for Graphics Card - TUF GAMING A620AM-PLUS series motherboards offer PCIe 4.0 slot connectivity for the GPUs. The wide bandwidth and superfast transmission speeds allow you to create feature-rich builds that can handle high loads effortlessly.
-
Rear USB 10Gbps Type-A - Extensive USB support ensures connections to a wide array of external devices. This motherboard includes two USB 10Gbps Type-A ports on the rear I/O panel that delivers transfer speeds of up to 10Gbps.
-
Front USB 5Gbps Type-C - This motherboard features a USB 5Gbps Type-C® front panel connector for speedy data transfers of up to 5Gbps.
Easy PC DIY
Protection
- SafeSlot Core+ - SafeSlot Core+ is the ASUS-exclusive PCIe slot fortified with a one-piece stainless-steel brace that shields the slot to protect it from damage. The metal cover is tightly secured to the slot with hooks, and the entire assembly is firmly anchored to the PCB with strengthened solder points to provide a secure foundation for heavyweight graphics cards.
- ESD Guards - ASUS added special TVS diodes to boost electrostatic discharge prevention by up to +/- 10 kV of air discharge and +/- 6 kV of contact discharge – well above the industry standard.
- TUF LANGuard - TUF LANGuard is a military-grade innovation that integrates advanced signal-coupling technology and premium surface-mounted capacitors to improve throughput, helping to protect the motherboard from lightning strikes and static electricity.
Ultrafast Networking
- WiFi 6 - WiFi 6 ensures stable connections and low latency.
- 2.5Gb Ethernet - On-board 2.5Gb Ethernet kicks your LAN connection up a notch by improving bandwidth speeds up to 2.5X faster than 1Gb connections.
Audio
- Realtek 7.1 Channel Audio - The unique audio codec designed in close collaboration with Realtek for TUF GAMING A620AM-PLUS series motherboards feature an unprecedented 98 dB signal-to-noise ratio for the stereo line out, providing pristine audio quality.
Lighting
- Outshine The Competition - ASUS Aura Sync offers synchronized lighting with other Aura Sync products, including motherboards, graphics cards, monitors and peripherals.
- Addressable Gen2 RGB Header - Automatically optimize lighting effects for the number of LEDs present in compatible ARGB gear.
Description
Specification
-
Motherboard Type: Desktop
-
Form Factor: Micro ATX
-
Socket: AMD AM5
-
Chipset: AMD A620A
-
#Hide#DDR Type: DDR5
-
CPU Support: Click here for CPU support
-
RAM Technology: "DDR5 (Dual Channel)
ECC and Non-ECC Un-buffered DIMM*
Supports AMD EXPO
ASUS AEMP
*Non-ECC, un-buffered DDR5 memory supports On-Die ECC function"
-
RAM Slots: 4 x DIMM
-
RAM Speeds: Up to 7600+MT/s(OC)
-
Maximum Memory: 256GB
-
Graphics: Integrated Graphics
Graphics specifications may vary between CPU types
-
Graphics Ports: 1 x HDMI
2 x DisplayPort
-
PCI/PCI Express: Ryzen 9000 & 7000 Series CPUs:
1 x PCIe 4.0 x16 (supports x16 mode)
Ryzen 8000 Series CPUs:
1 x PCIe 4.0 x16 (supports x8/x4 mode)
AMD B850 Chipset:
1 x PCIe 3.0 x1
-
Storage: 2 x SATA III
3 x M.2
Ryzen 9000 & 7000 Series CPUs:
M.2_1 (2280) - PCIe 4.0 x4
M.2_2 (2242/2260/2280) - PCIe 4.0 x4
Ryzen 8000 Series CPUs:
M.2_1 (2280) - PCIe 4.0 x4
M.2_2 (2242/2260/2280) - PCIe 4.0 x4/x2
-
RAID: Ryzen 9000 Series CPUs: RAID 0/1/5/10
Ryzen 8000 Series CPUs: RAID 0/1
Ryzen 7000 Series CPUs: RAID 0/1/10
-
Wireless: Wi-Fi 6
1x1 Wi-Fi 6 (802.11 a/b/g/n/ac/ax)
Supports 2.4/5GHz frequency band
Bluetooth v5.3
-
LAN: 2.5GB LAN
-
Audio: Realtek 7.1 Surround Sound High Definition Audio CODEC
-
USB Ports Supported: Rear:
2 x USB 10Gbps Type-A
4 x USB 2.0
Front:
1 x USB 5Gbps Type-C
2 x USB 5Gbps
4 x USB 2.0
-
Back Panel I/O Ports: 2 x USB 10Gbps Type-A
4 x USB 2.0
2 x DisplayPort
1 x HDMI
1 x Wi-Fi module
1 x Realtek 2.5Gb Ethernet
3 x Audio jacks
1 x BIOS FlashBack button
1 x PS/2 keyboard/mouse combo
-
Internal I/O Connectors: 1 x 4-pin CPU Fan
2 x 4-pin Chassis Fan
1 x 24-pin Main
1 x 8-pin +12V CPU
2 x M.2 (Key M)
4 x SATA 6Gb/s
1 x USB 5Gbps Type-C
1 x USB 5Gbps
2 x USB 2.0
3 x Addressable RGB Gen2
1 x Clear CMOS
1 x COM Port
-
.: 1 x Front Panel Audio
1 x S/PDIF Out
1 x 10-1 pin Front Panel System
-
Accessories: 2 x SATA 6Gb/s cables
1 x ASUS Wi-Fi moving antenna
1 x I/O shield
2 x Screw packages for M.2 SSD
1 x TUF GAMING sticker
1 x Quick start guide
-
Additional Features: See Overview
-
Package Type: Retail
-
Package Weight: To be confirmed
-
Warranty: 3 Years
-
#Hide#M.2 Slot(s): Yes (M.2)
-
#Hide#No. LAN Ports: 1 x LAN
-
#Hide#Max LAN Speed: 2.5GB LAN
-
#Hide#Wi-Fi: Yes (Wi-Fi)
