Brand MSI
Title MSI PRO B760-P WIFI DDR4, Intel B760, 1700, ATX, 4 DDR4, HDMI, DP, Wi-Fi 6E, 2.5G LAN, 2x M.2

MSI PRO B760-P WIFI DDR4, Intel B760, 1700, ATX, 4 DDR4, HDMI, DP, Wi-Fi 6E, 2.5G LAN, 2x M.2

SKU: PRO B760-P WIFI DDR4
Price
£142.00
Tax included. Shipping calculated at checkout.
In stock online and ready for delivery or collection
Apple Pay
Google Pay
Klarna
Maestro
Mastercard
PayPal
Shop Pay
Visa

Share this product

Share Post E-mail
MSI PRO B760-P WIFI DDR4, Intel B760, 1700, ATX, 4 DDR4, HDMI, DP, Wi-Fi 6E, 2.5G LAN, 2x M.2

MSI PRO B760-P WIFI DDR4, Intel B760, 1700, ATX, 4 DDR4, HDMI, DP, Wi-Fi 6E, 2.5G LAN, 2x M.2

£142.00

Product Information



PRO B760-P DDR4 is designed with tons of flexible tools with DDR4 memory version.

  • Support Intel® Core™ 14th/ 13th/ 12th Gen Processors, Intel® Pentium® Gold and Celeron® Processors for LGA 1700 socket
  • Supports DDR4 Memory, Dual Channel DDR4 5333+MHz (OC)
  • Enhanced Power Design: 12+1 Duet Rail Power System with P-PAK, 8-pin + 4-pin CPU power connectors, Core Boost, Memory Boost
  • Premium Thermal Solution: Extended Heatsink, MOSFET thermal pads rated for 7W/mK, additional choke thermal pads and M.2 Shield Frozr are built for high performance system and non-stop gaming experience
  • High Quality PCB: 6-layer PCB made by 2oz thickened copper
  • Lightning Fast Game experience: PCIe 4.0 slot, Lightning Gen 4 x4 M.2
  • Intel Turbo USB 3.2 Gen 2: Powered by Intel USB 3.2 Gen2 controller, Turbo USB ensures an uninterrupted connection with more stability and fastest USB speeds
  • 2.5G LAN with Wi-Fi 6E Solution: Upgraded network solution for professional and multimedia use. Delivers a secure, stable and fast network connection
  • Audio Boost: Reward your ears with studio grade sound quality for the most immersive gaming experience





Business Elegance Redefined

The PRO Series is tailored to professionals from all walks of life. The lineup features impressive performance and high quality, while aiming to provide users incredible experience. Users who care about productivity and efficiency can definitely count on the MSI PRO Series to assist you with multitasking and increasing efficiency.





Lightning Gen4 Solution

The latest Gen4 PCI-E and M.2 solution with up to 64GB/s bandwidth for maximum transfer speed.





Wi-Fi 6E

The latest wireless solution supports 6GHz spectrum, MU-MIMO and BSS color technology, delivering speeds up to 2400Mbps.





Extended Heatsink Design

MSI extended PWM heatsink and enhanced circuit design ensures even high-end processors to run in full speed.





M.2 Shield FROZR

Strengthened built-in M.2 thermal solution. Keeps M.2 SSDs safe while preventing throttling, making them run faster.





2.5G Network Solution

Featuring premium 2.5G LAN to deliver better network experience.





EZ Debug LED

Easiest way to troubleshoot.





Frozr AI Cooling

Detect CPU & GPU temperatures and automatically adjust system fan duty to a proper value.





Memory Boost

Advanced technology to deliver pure data signals for the best performance, stability and compatibility.





Core Boost

With premium layout and fully digital power design to support more cores and provide better performance.



Description

Specification

  • Motherboard Type: Desktop
  • Form Factor: ATX
  • Socket: Intel 1700
  • Chipset: Intel B760
  • #Hide#DDR Type: DDR4
  • CPU Support: Click here for CPU support
  • RAM Technology: "DDR4 (Dual Channel)
    Supports non-ECC, un-buffered memory
    Supports Intel Extreme Memory Profile (XMP)"
  • RAM Slots: 4 x DIMM
  • RAM Speeds: Up to 5333(OC)
  • Maximum Memory: 128GB
  • Graphics: Integrated Graphics
    Graphics specifications may vary between CPU types
  • Graphics Ports: 1 x HDMI
    1 x DisplayPort
  • PCI/PCI Express: 2 x PCIe 4.0 x16
    3 x PCIe 3.0 x1
  • Storage: 4 x SATA III
    2 x M.2

    M.2_1 (22110/2280/2260/2242) - PCIe 4.0 x4
    M.2_2 (2280/2260/2242) - SATA & PCIe 4.0 x4
  • RAID: "Supports RAID 0, 1, 5 and 10 for SATA storage devices"
  • Wireless: "Intel Wi-Fi 6E
    The Wireless module is pre-installed in the M.2 (Key-E) slot
    Supports MU-MIMO TX/RX, 2.4GHz / 5GHz / 6GHz (160MHz) up to 2.4Gbps
    Supports 802.11 a/ b/ g/ n/ ac/ ax
    Supports Bluetooth 5.3, FIPS, FISMA"
  • LAN: 2.5GB LAN
  • Audio: Realtek ALC897 Codec
    7.1-Channel High Definition Audio
  • USB Ports Supported: Rear:
    1 x USB 10Gbps Type-C
    2 x USB 10Gbps Type-A
    4 x USB 2.0

    Front:
    1 x USB 5Gbps Type-C
    2 x USB 5Gbps Type-A
    4 x USB 2.0
  • Back Panel I/O Ports: 1 x USB 10Gbps Type-C
    2 x USB 10Gbps Type-A
    4 x USB 2.0
    1 x DisplayPort 1.4
    1 x HDMI 2.1
    1 x RJ-45
    1 x Audio Line In
    1 x Audio Line Out
    1 x Microphone In
    1 x S/PDIF Optical Out
    2 x SMA Antenna
  • Internal I/O Connectors: 1 x Power (ATX_PWR)
    2 x Power (CPU_PWR)
    1 x CPU Fan
    1 x Pump Fan
    5 x System Fan
    2 x Front Panel
    1 x Chassis Intrusion
    1 x Front Audio
    1 x Printer Port
    1 x Com Port
    2 x Addressable V2 RGB LED
    1 x RGB LED
  • .: 1 x TPM pin TPM 2.0
    4 x USB 2.0
    2 x USB 5Gbps Type-A
    1 x USB 5Gbps Type-C
  • Accessories: EU Regulatory Notice
    Quick Installation Guide
    EZ M.2 Clip
    SATA Cable
    Wi-Fi Antenna
    I/O Shield
  • Additional Features: See Overview
  • Package Type: Retail
  • Package Weight: To be confirmed
  • Warranty: 3 Years
  • #Hide#M.2 Slot(s): Yes (M.2)
  • #Hide#No. LAN Ports: 1 x LAN
  • #Hide#Max LAN Speed: 2.5GB LAN
  • #Hide#Wi-Fi: Yes (Wi-Fi)
